SSB F Super VT Series

SSB F Super VT Series drill presses are the right choice for any workshop, from maintenance to finishing. These rugged drill presses feature a touchscreen control panel display that also provides user support for selecting the right operating parameters.

2 models · Drilling capacity 1.57–1.97 in · Throat depth 13–14 in

Call
More about the series ↓

The 2 SSB F Super VT models

Sorted by size

Model Drilling capacityThroat depthMotor rating main drive Stock Request a quote
SSB 40 F Super VTItem No. 162334
Drilling capacity1.57 in
Throat depth13 in
Motor rating main drive2.7 Hp
Details
SSB 50 F Super VTItem No. 101679
Drilling capacity1.97 in
Throat depth14 in
Motor rating main drive4 Hp
Details

You will receive price and delivery time free of charge by email. Not sure which model fits?

All technical data compared
Feature SSB 40 F Super VTSSB 50 F Super VT
Drilling capacity 1.57 in1.97 in
Tapping capacity, steel M 24M 30
Quill stroke 7 in8 in
Powered table travel 16.93 in15.94 in
Column diameter 6 in7 in
Throat depth 13 in14 in
Speed range 60 rpm - 2,600 rpm50 rpm - 2,000 rpm
Motor rating main drive 2.7 Hp4 Hp
Overall dimensions (length x width x height) 35 in x 26 in x 88 in39 in x 27 in x 93 in
Weight 1,243 lbs1,584 lbs
Data sheet PDFPDF

Standard on every SSB F Super VT

  • Touchscreen controller
  • Thread cutting function
  • Automatic spindle feeds
  • Motorized table height adjustment
  • Drilling accessories
  • Coolant system
  • Protective shield
  • LED work lamp
  • Operating manual

About the SSB F Super VT series

SSB F Super VT Series drill presses are the right choice for any workshop, from maintenance to finishing. These rugged drill presses feature a touchscreen control panel display that also provides user support for selecting the right operating parameters. The spindle speed is infinitely variable, and the quill feed features a rugged manual transmission. The setup table has motorized vertical movement for easier handling of heavy parts. These drill presses are ideal for custom and small-series machining, but also for maintenance and in the steel and industrial construction sector.
